ADL Rex Junior
Classification 12 23 06 - 08
Powered wheelchairs, powered steering, class B (for indoor and outdoor use)
Powered wheelchairs, powered steering, class B (for indoor and outdoor use)
The product series contains 4 products.
Product 1 of 4 - ADL Rex Junior, SW 20 cm
HMI-no. 69850
Registration date 06-12-2011
Last updated 18-12-2012
Specifications
| User weight max. | 50 | kg |
| Width | 410 | mm |
| Length | 700 | mm |
| Weight | 32 | kg |
| Programmable | Yes | |
| Speed max. | 9 | km/t |
| Driving distance range, fully charged | 25 | km |
| Elevating seat | No | |
| Seat height, min. | 320 | mm |
| Seat height, max. | 420 | mm |
| Powered recline | No | |
| Back rest recline max. | 30 | grader |
| Powered tilt | No | |
| Tilt-in-space forward | 0 | grader |
| Tilt-in-space back | 6 | grader |
| Powered legrests | No | |
| Optional motorized attendant control | Yes | |
| Ground clearance | 60 | mm |
| Turning diameter | 700 | mm |
| Slope max. | 6 | grader |
| Climbs obstacles of max. | 50 | mm |
| Suspension | No | |
| Front-wheel-driven | No | |
| Mid-wheel-driven | No | |
| Rear-wheel-driven | Yes | |
| Can be used as seat in a car | Yes |
Product 2 of 4 - ADL Rex Junior, SW 24 cm
HMI-no. 69985
Registration date 21-12-2011
Last updated 18-12-2012
Specifications
| User weight max. | 50 | kg |
| Width | 410 | mm |
| Length | 700 | mm |
| Weight | 32 | kg |
| Programmable | Yes | |
| Speed max. | 9 | km/t |
| Driving distance range, fully charged | 25 | km |
| Elevating seat | No | |
| Seat height, min. | 320 | mm |
| Seat height, max. | 420 | mm |
| Powered recline | No | |
| Back rest recline max. | 30 | grader |
| Powered tilt | No | |
| Tilt-in-space forward | 0 | grader |
| Tilt-in-space back | 6 | grader |
| Powered legrests | No | |
| Optional motorized attendant control | Yes | |
| Ground clearance | 60 | mm |
| Turning diameter | 700 | mm |
| Slope max. | 6 | grader |
| Climbs obstacles of max. | 50 | mm |
| Suspension | No | |
| Front-wheel-driven | No | |
| Mid-wheel-driven | No | |
| Rear-wheel-driven | Yes | |
| Can be used as seat in a car | Yes |
Product 3 of 4 - ADL Rex Junior, SW 28 cm
HMI-no. 69986
Registration date 21-12-2011
Last updated 18-12-2012
Specifications
| User weight max. | 50 | kg |
| Width | 410 | mm |
| Length | 700 | mm |
| Weight | 32 | kg |
| Programmable | Yes | |
| Speed max. | 9 | km/t |
| Driving distance range, fully charged | 25 | km |
| Elevating seat | No | |
| Seat height, min. | 320 | mm |
| Seat height, max. | 420 | mm |
| Powered recline | No | |
| Back rest recline max. | 30 | grader |
| Powered tilt | No | |
| Tilt-in-space forward | 0 | grader |
| Tilt-in-space back | 6 | grader |
| Powered legrests | No | |
| Optional motorized attendant control | Yes | |
| Ground clearance | 60 | mm |
| Turning diameter | 700 | mm |
| Slope max. | 6 | grader |
| Climbs obstacles of max. | 50 | mm |
| Suspension | No | |
| Front-wheel-driven | No | |
| Mid-wheel-driven | No | |
| Rear-wheel-driven | Yes | |
| Can be used as seat in a car | Yes |
Product 4 of 4 - ADL Rex Junior, SW 32 cm
HMI-no. 69987
Registration date 21-12-2011
Last updated 18-12-2012
Specifications
| User weight max. | 50 | kg |
| Width | 410 | mm |
| Length | 700 | mm |
| Weight | 32 | kg |
| Programmable | Yes | |
| Speed max. | 9 | km/t |
| Driving distance range, fully charged | 25 | km |
| Elevating seat | No | |
| Seat height, min. | 320 | mm |
| Seat height, max. | 420 | mm |
| Powered recline | No | |
| Back rest recline max. | 30 | grader |
| Powered tilt | No | |
| Tilt-in-space forward | 0 | grader |
| Tilt-in-space back | 6 | grader |
| Powered legrests | No | |
| Optional motorized attendant control | Yes | |
| Ground clearance | 60 | mm |
| Turning diameter | 700 | mm |
| Slope max. | 6 | grader |
| Climbs obstacles of max. | 50 | mm |
| Suspension | No | |
| Front-wheel-driven | No | |
| Mid-wheel-driven | No | |
| Rear-wheel-driven | Yes | |
| Can be used as seat in a car | Yes |
