The product series contains 2 products.
The product series also includes 2 discontinued products. Include discontinued products.

Specifications summarized

Specifications for the 2 products in the product series. Click a HMI-no. to see all details for a single product.

Product 1 - 2
Specification/HMI-no.	100144	100145
Height adjustable	Manuelt	Manuelt
Tension adjustable back rest upholstery	Yes	Yes
Can be used with standard wall-mounted toilets (without extension)	Yes	Yes
Possibility to change position of armrest to allow sideways transfer	Yes	Yes
Head support	Yes	Yes
Fold-up foot supports	Yes	Yes
Height adjustable legrests	Yes	Yes
Elevating legrests	Yes	Yes
Legrest position may be changed to facililtate hygiene and transfer	Yes	Yes
User weight, max (kg)	150	150
Total width (cm)	57	57
Ground clearance (cm) Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.	52.5	52.5
Width between arm supports (cm) Smallest distance measured between the inside of the arm supports. If the arm supports are adjustable, this is measured with the arm supports in the widest position.	46	46
Seat depth (cm) If the seat depth is adjustable, this is the maximum seat depth	44	44
Seat height, min (cm)	55.5	55.5
Seat height, max (cm)	61.5	61.5
Tilt-in-space forward (°) Measured from the horizontal position.	7	7
Tilt-in-space back (°) Measured from the horizontal position.	37	37
Number of wheels with brake	4	4
Wheel diameter (mm)	125	125
Height of push handles/push bar, min. (cm) Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.	100	100
Height of push handles/push bar, max. (cm) Measured from the floor to the upper surface of the heigher grip with the chair in the highest position	106	106
