R44 Lightning RWD TB-Flex
Classification
12 23 06 08 - Powered wheelchairs, powered steering, class B (for indoor and outdoor use)
The product series contains 1 product.
Product 1 of 1
R44 Lightning RWD TB-Flex
HMI-no.
115885
Article-no.
2400-1227
Registration date
14-05-2019
Last updated
15-05-2025
Properties
Intended for children
No
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Programmable
Yes
Elevating seat
No
Powered recline
No
Powered tilt
Yes
Powered legrests
No
Optional motorized attendant control
Yes
Suspension
Yes
Front-wheel-driven
No
Mid-wheel-driven
No
Rear-wheel-driven
Yes
Can be used as seat in a car
Yes
Measures
User weight, max
136
kg
External width
64
cm
Measured where widest
External length
119
cm
Maximum external length with the seat in an upright position. Measured without leg supports
Weight
140
kg
Speed, max
10
km/t
Driving distance range, fully charged
30
km
The theoretical driving distance range as calculated through laboratory testing.
Seat height, min
43
cm
The vertical distance between the floor and the seat surface measured at the front edge of the seat. Measured with the seat in the lowest position.
Seat height, max
43
cm
The vertical distance between the floor and the seat surface measured at the front edge of the seat. Measured with the seat in the highest position.
Back rest recline, max
125
°
Recline of back rest from an upright position.
Tilt-in-space forward
0
°
Measured from the horizontal position.
Tilt-in-space back
30
°
Measured from the horizontal position.
Ground clearance
6
cm
Slope, max
6
°
Climbs obstacles of max
6
cm
Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12184:2009: Electrically powered wheelchairs, scooters and their chargers - Requirements and test methods.
Test lab: CERT, Berlin, Tyskland. Test date: 23-07-2014
Test report for HMI-no. 115885
Test lab: CERT, Berlin, Tyskland. Test date: 23-07-2014
Test report for HMI-no. 115885EU product safety regulation
No information about CE-marking
The supplier has not provided any information about CE-marking of the product. Explain CE-marking
