The product series contains 7 products.

Specifications summarized

Specifications for the 7 products in the product series. Click a HMI-no. to see all details for a single product.

Product 1 - 7
Specification/HMI-no.	133281	133512	133515	133518	133521	133524	133527
Adjustable seat width	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Adjustable seat depth	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Height adjustable back rest	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Front-wheel-driven	No	No	No	No	No	No	No
Can be subsequently equipped with propulsion unit	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Can be mounted on a stair climber	No	No	No	No	No	No	No
Intended for fastening in a car	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Can be supplied with electrically operated tilt-in-space	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Can be supplied with electrically operated back-rest recline	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Head support	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Can be supplied with central legrest	No	No	No	No	No	No	No
Balance point adjustable	No	No	No	No	No	No	No
Adjustable push handles	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Wheels with handrims	No	No	No	No	No	No	No
Transit wheels	No	No	No	No	No	No	No
Foldable	No	No	No	No	No	No	No
Seat width, min (cm)	34	34	40	40	40	46	46
Seat width, max (cm)	40	40	46	46	46	52	52
Seat depth, min (cm)	40	46	40	46	52	46	52
Seat depth, max (cm)	44	50	44	50	56	50	56
Seat height, min (cm)	60	60	60	60	60	60	60
Seat height, max (cm)	71	72	72	72	72	72	72
Back rest height, min. (cm)	50	50	50	50	50	50	50
Back rest height, max (cm)	52.5	52.5	52.5	52.5	52.5	52.5	52.5
Total width (cm) The narrowest possible configuration.	69.5	83	83	83	83	83	83
Total length (cm)	110	110	110	110	110	110	110
Weight (kg) The stated weight of the wheelchair is incl. wheels and leg supports.	47	47	47	47	47	47	47
User weight, max (kg)	140	140	140	140	140	140	140
Tilt-in-space forward (°) Measured from the horizontal position.	0	0	0	0	0	0	0
Tilt-in-space back (°) Measured from the horizontal position.	45	45	45	45	45	45	45
Back rest recline, max (°) Recline of back rest from an upright position.	131	131	45	45	45	45	45
