Symbliss Bath Chair



The Symbliss bathing chair is part of an integrated bathing system for care recipients at all mobility levels. The design supports caregivers in performing hygiene tasks efficiently and ergonomically. The chair enables a short bathing break with focus on physical comfort and safety.

Classification
09 12 03 11 - Commode shower chairs with wheels, tilt and electrical functions

Documents
Brochure
User manual
QuickGuide


The product series contains 2 products.

» Summarize specifications

Product 1 of 2
Symbliss Bath Chair with weight


HMI-no.
144526
Article-no.
SYBCS011-DK

Registration date
19-05-2025
Last updated
11-09-2025

Properties
Height adjustable
Elektrisk
Tension adjustable back rest upholstery
No
Can be used with standard wall-mounted toilets (without extension)
No
Possibility to change position of armrest to allow sideways transfer
No
Powered tilt
Yes
Tilt-in-space dissociated from the height adjustment
No
The function of the tilt-in-space is separated from the hydraulic or electrical function of the height adjustment.
Head support
No
Battery chargeable separated from the product
Yes
Emergency stopping function
Yes
Fold-up foot supports
No
Height adjustable legrests
No
Elevating legrests
No
Legrest position may be changed to facililtate hygiene and transfer
Yes

Measures
User weight, max
200
kg
Total width
70.3
cm
Ground clearance
12.8
cm
Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.
Width between arm supports
47
cm
Smallest distance measured between the inside of the arm supports. If the arm supports are adjustable, this is measured with the arm supports in the widest position.
Seat depth
50
cm
If the seat depth is adjustable, this is the maximum seat depth
Wheel diameter
100
mm
Number of wheels with brake
4
Seat height, min
50
cm
Seat height, max
100
cm
Tilt-in-space forward
3
°
Measured from the horizontal position.
Tilt-in-space back
25
°
Measured from the horizontal position.
Height of push handles/push bar, min.
117
cm
Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.
Height of push handles/push bar, max.
117.8
cm
Measured from the floor to the upper surface of the heigher grip with the chair in the highest position
Ingress protection class for water
4
IP
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 144526

Product 2 of 2
Symbliss Bath Chair without weight


HMI-no.
144527
Article-no.
SYBCS001-DK

Registration date
19-05-2025
Last updated
11-09-2025

Properties
Height adjustable
Elektrisk
Tension adjustable back rest upholstery
No
Can be used with standard wall-mounted toilets (without extension)
No
Possibility to change position of armrest to allow sideways transfer
No
Powered tilt
Yes
Tilt-in-space dissociated from the height adjustment
No
The function of the tilt-in-space is separated from the hydraulic or electrical function of the height adjustment.
Head support
No
Battery chargeable separated from the product
Yes
Emergency stopping function
Yes
Fold-up foot supports
No
Height adjustable legrests
No
Elevating legrests
No
Legrest position may be changed to facililtate hygiene and transfer
Yes

Measures
User weight, max
200
kg
Total width
70.3
cm
Ground clearance
12.8
cm
Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.
Width between arm supports
47
cm
Smallest distance measured between the inside of the arm supports. If the arm supports are adjustable, this is measured with the arm supports in the widest position.
Seat depth
50
cm
If the seat depth is adjustable, this is the maximum seat depth
Wheel diameter
100
mm
Number of wheels with brake
4
Seat height, min
50
cm
Seat height, max
100
cm
Tilt-in-space forward
3
°
Measured from the horizontal position.
Tilt-in-space back
25
°
Measured from the horizontal position.
Height of push handles/push bar, min.
117
cm
Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.
Height of push handles/push bar, max.
117.8
cm
Measured from the floor to the upper surface of the heigher grip with the chair in the highest position
Ingress protection class for water
4
IP
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 144527
